CHAPTER 2CHAPTER 2

CHAPTER 2

HARDHARD

HARD

ARE INSTARE INST

ARE INST

ALLAALLA

ALLA

TIONTION

TION

2-35

2.14 Audio Port Connectors

Line Out is a connector for Speakers or Headphones. Line In is used for

external CD player, Tape layer, or other audio devices. Mic is a connector for

the microphones.

Line Out

Line In

Mic

1/8” Stereo Audio Connectors

2.13 Joystick/Midi Connectors

You can connect joystick or game pad to this connector.

Joystick/MIDI

NOTE: Line Out supports SPDIF converter. In case, you use the SPDIF

converter, change the output mode to digital on the audio setting.
