CHAPTER 2CHAPTER 2

CHAPTER 2

HARDHARD

HARD

ARE INSTARE INST

ARE INST

ALLAALLA

ALLA

TIONTION

TION

2-10

Step 3: Install the Heat Sink Support Base.

Look for the 2 holes across Slot 1, and match it with the 2 Heat Sink

Support Base. Take note that one hole/base is bigger than the other.

Push the Heat Sink Support Base onto the mainboard, until you hear

a click sound. Check for a perfect fit.

PC-3742

Retention

Mechanism

Notch

Hole

Heat Sink

Support Base
